Introduction

In industrial waste processing and plastic recycling, the demand for high-capacity, reliable crushing solutions is paramount. The 3000 Series large plastic crushers meet this need with exceptional design, combining heavy-duty construction, intelligent controls, and customizable configurations to tackle even the most challenging materials. Whether processing 100+ tons of plastic pallets, car bumpers, or industrial waste daily, these crushers ensure consistent performance, minimal downtime, and superior output quality. This article provides an in-depth look at the 3000 Series, its core technologies, and how it transforms high-volume plastic processing.

1. Core Design Philosophy of the 3000 Series

1.1 Engineered for Massive Throughput

• High-Torque Performance: Designed to handle 3–8 tons/hour, depending on material type, with motors ranging from 200–500 kW to drive through tough, composite materials.
• Durability First: Heavy-duty steel frames (Q345B), wear-resistant shafts, and replaceable components ensure 24/7 operation in harsh environments.
• Smart Automation: Integrates PLC controls and IoT monitoring to optimize speed, torque, and energy use in real time.

1.2 Key Components Explained

1.2.1 Dual-Shaft Shredder (3000DS Model)

• Counter-Rotating Shafts:
  Two 300mm-diameter shafts with interlocking carbide teeth (speed difference 8–10%) generate 1,500 kN·m torque, ideal for oversized materials like 1200×1000mm pallets.
• Hydraulic Overload Protection:
  Sensors detect metal or glass contaminants, triggering automatic shaft reversal to prevent damage, reducing maintenance costs by 40%.

1.2.2 Precision Blade Crusher (3000BC Model)

• High-Speed Shearing System:
  24 SKD11 steel blades (rotating at 500 RPM) create a 0.5mm shear gap, producing uniform 8–30mm particles for rigid plastics like PET and ABS.
• Adjustable Screening Module:
  Quick-release stainless steel screens (304 材质) allow switching between 10–50mm mesh sizes in 15 minutes, adapting to downstream needs.

1.2.3 Claw Crusher (3000CC Model)

• Anti-Entanglement Design:
  12 pairs of Teflon-coated claws (2,800 RPM) with 12mm spacing tear soft films (PE/PP) without jams, handling up to 20% moisture content.
• Variable Frequency Drive (VFD):
  Automatically adjusts speed based on material thickness, improving efficiency by 25% for wet agricultural film.

2. Technical Specifications: 3000 Series Models

2.1 Dual-Shaft Shredder (3000DS)

2.2 Precision Blade Crusher (3000BC)

2.3 Claw Crusher (3000CC)

3. Applications: Where the 3000 Series Shines

3.1 Large-Scale Plastic Recycling Plants

Case: PET Bottle Recycling (3000BC Model)

• Setup: 3000BC with 12mm screen + three-stage washing line + AI sorter.
• Process:
  1. Crush 6 tons/hour of post-consumer PET bottles into 10mm flakes.
  2. Wash to 99.9% purity for 纺丝级 (spinning-grade) polyester production.
• Advantages:
  • YG8 blades last 1,500 hours in abrasive PET, 50% longer than standard steel.
  • PLC control reduces energy use by 20% during low-load periods.

Case: Mixed Waste Processing (3000DS Model)

• Setup: 3000DS dual-shaft + magnetic separator + secondary crusher.
• Process:
  1. Shred 8 tons/hour of pallets, bumpers, and industrial waste into 50mm fragments.
  2. Separate metal contaminants (98% removal rate) before secondary processing.
• Advantages:
  • Hydraulic system safely ejects metal bolts, protecting downstream equipment from damage.
  • Modular shaft design allows quick tooth replacement, reducing downtime by 60%.

3.2 Manufacturing Waste Management

Case: Injection Molding Scrap (3000BC Model)

• Setup: 3000BC with 20mm screen + conveyor integration.
• Process:
  1. Recycle 5 tons/hour of ABS/PC trimmings into uniform granules.
  2. Reuse in injection molding machines (up to 30% blend with virgin material).
• Advantages:
  • 95% particle uniformity ensures smooth feeding into molding machines, reducing defects by 25%.
  • Compact design fits into tight factory spaces, with soundproof enclosures meeting OSHA noise standards.

3.3 Logistics and Pallet Recycling

Case: Damaged Pallet Processing (3000DS Model)

• Setup: 3000DS with 2200×2400mm inlet + automated feeding system.
• Process:
  1. Shred 100 pallets/hour (1.2m×1m size) into 80mm fragments.
  2. Wash and pelletize for new pallet production or composite material manufacturing.
• Advantages:
  • Single-pass processing eliminates pre-cutting, saving 40% labor costs compared to manual methods.
  • IoT monitoring tracks shaft wear in real time, enabling predictive maintenance and 30% longer component life.

4. Key Factors in Choosing the Right 3000 Series Model

4.1 Material Type & Hardness

• Rigid Plastics (ABS, PET, PVC):
  Choose 3000BC for precision shearing, with screen size matching downstream needs (10mm for 纺丝，20mm for injection molding).
• Soft/Flexible Materials (PE Film, PP Bags):
  3000CC’s anti-entanglement design and high-speed claws ensure continuous processing without jams.
• Large/Composite Waste (Pallets, Bumpers):
  3000DS dual-shaft model provides the torque needed for oversized items, even with metal inclusions.

4.2 Processing Capacity

• 50–100 Tons/Day:
  Single 3000BC or 3000CC model with semi-automatic feeding, ideal for medium recycling centers.
• 200+ Tons/Day:
  Multiple 3000DS shredders paired with conveyors and sorting systems, optimized for 24/7 industrial operations.

4.3 Automation & Control

• Basic Automation:
  PLC control for speed adjustment (standard in all models), suitable for consistent material types.
• Advanced Integration:
  IoT-enabled models (optional) for remote monitoring, data analytics, and predictive maintenance, reducing downtime by 40%.

4.4 Compliance & Safety

• Environmental Standards:
  Models with CE, ISO 9001, and SGS certifications ensure compliance with EU, US, and Asian regulations.
• Safety Features:
  Emergency stop systems, overload protection, and enclosed chambers reduce operator risk in high-volume settings.

5. Case Studies: 3000 Series in Real-World Operations

Case 1: North American PET Recycling Giant

• Challenge: Process 500 tons/day of post-consumer PET bottles into food-grade flakes.
• Solution:
  • Four 3000BC models with 10mm screens and stainless steel components.
  • Integrated with optical sorters and reverse-flow washing lines.
• Outcome:
  • 8 tons/hour throughput per machine, meeting FDA purity standards for food contact applications.
  • 25% reduction in energy costs via VFD and IE5 motors, with a 12-month ROI.

Case 2: Automotive Waste Processing in Germany

• Challenge: Crush 300 tons/day of mixed car parts, including rubber-lined bumpers and plastic interiors.
• Solution:
  • Two 3000DS high-torque models with self-cleaning teeth and hydraulic metal ejection.
  • Paired with eddy current separators for non-ferrous metal recovery.
• Outcome:
  • 9 tons/hour processing speed, with 99% metal removal and 85% plastic recovery for secondary use.
  • Compliance with EU End-of-Life Vehicle Directive (ELV) standards.

Case 3: Logistics Hub in Southeast Asia

• Challenge: Recycle 200 tons/day of damaged plastic pallets from e-commerce packaging.
• Solution:
  • Three 3000DS standard models with 1800×2000mm inlets and magnetic separators.
  • Automated conveyor system for seamless feeding and screening.
• Outcome:
  • 5 tons/hour per machine, eliminating manual dismantling and reducing waste disposal costs by 60%.
  • Recycled pallet fragments used to produce new packaging materials, supporting circular economy goals.

6. Common Questions About the 3000 Series

6.1 What Is the Lifespan of Key Components?

• Blades/Teeth:
  • Standard steel: 800–1,000 hours (3000BC/3000CC).
  • Carbide-alloy: 1,500–2,000 hours (3000DS high-torque models).
• Motors:
  5–10 years with regular maintenance (lubrication, bearing checks), supported by 2-year warranties.

6.2 Can These Crushers Handle Wet or Contaminated Materials?

• Yes:
  • 3000CC wet-material model handles 25% moisture with corrosion-resistant coatings.
  • 3000DS hydraulic system ejects contaminants, while optional washing lines remove dirt/debris pre-crushing.

6.3 How Much Space Is Required for Installation?

• Footprint:
  • 3000BC: 4m × 3m × 3.5m (L×W×H), suitable for industrial 厂房 (factories) with 5m ceiling height.
  • 3000DS: 6m × 4m × 4m, requiring overhead crane access for material loading.

6.4 Are Customizations Available for Unique Needs?

• Absolutely:
  • Inlet size, screen mesh, and material coatings can be customized.
  • Example: A pharmaceutical client requested FDA-compliant 304 stainless steel interiors for processing medical-grade plastic waste.

7. Innovations in the 3000 Series

7.1 AI-Powered Process Optimization

• Technology:
  Machine learning algorithms analyze real-time torque and motor data to adjust shaft speed, optimizing for material hardness and reducing energy waste by 15%.
• Benefit:
  Self-calibrating performance ensures consistent output quality, even with material variability.

7.2 Modular Design for Quick Maintenance

• Feature:
  Quick-release blade/claw modules and bolted shaft segments allow component replacement in <90 minutes, compared to 4+ hours for traditional designs.
• Impact:
  Reduces unplanned downtime by 70%, critical for 24/7 production environments.

7.3 Sustainable Engineering

• Eco-Features:
  • 30% recycled steel in frame construction.
  • Energy recovery systems capturing 10% of braking energy for reuse in facility lighting.

Conclusion
